NATE 1600W Grid-Tie Micro Inverter | 4×MPPT, 230V AC, WiFi Monitoring, IP67 (280W–550W per Panel)
NATE-Volt 1600 · Grid-Tie Micro Inverter
- 1600W total output across 4 independent MPPT inputs (280W–550W per panel)
- 230V AC grid-tie output, ideal for EU home solar systems
- 5%–100% adjustable output via app — match local grid requirements
- Real-time WiFi monitoring with the Solarman app & web platform
- IP67 waterproof, fanless silent cooling, zero maintenance
Delivery in 2–5 business days across the EU · Dispatched from Germany
Engineered for Maximum Harvest
4 Independent MPPT Inputs
Each of the four inputs tracks its own panel's maximum power point at 99.5% efficiency — mix orientations, tilt angles or panel types without one shaded string dragging down the whole array.
5%–100% Adjustable Output
Dial output up or down right from the app to comply with local feed-in limits or match household demand — flexible, efficient energy control at your fingertips.
Real-Time WiFi Monitoring
Watch live power curves, daily yield, error codes and system status from anywhere with the Solarman app and web platform.
IP67 · Fanless & Silent
Sealed against dust and rain, cooled by natural convection — no fans to wear out, silent operation, and zero maintenance for years on the wall.
Ships from Germany
Dispatched from our EU warehouse within 48 hours — 2–5 day delivery across Europe, no customs delays, VAT-friendly B2B invoicing.
Package Includes
Everything you need, in one box
- 1 × NATE 1600W grid-tie micro inverter (4 × MPPT)
- 1 × WiFi monitoring module
- 1 × AC connection cable
- 4 × pairs of MC4 DC input connectors
- 1 × Quick-start guide with mounting hardware
Full Specifications
| Rated Output Power | 1600W (4 × 400W) |
|---|---|
| AC Output | 230V AC, 50Hz — grid-tie |
| MPPT Inputs | 4 × independent, 25–55V DC per input |
| Recommended Panel Range | 280W – 550W per panel |
| MPPT Tracking Efficiency | 99.5% |
| Output Adjustment Range | 5% – 100% (app-controlled) |
| Monitoring | WiFi 2.4GHz — Solarman app & web platform |
| Protection Rating | IP67 — dustproof & waterproof |
| Cooling | Fanless natural convection |
| Operating Temperature | -25°C to 60°C |
| Certifications | CE |
| Dispatch | From German warehouse — 2–5 business days across the EU |
Specifications are measured under standard test conditions (STC).
Questions, Answered
What panels work with this inverter?
Any panel rated 280W–550W whose working voltage (Vmp) sits within the 25–55V DC input window. Each of the 4 MPPT inputs takes one panel, and different wattages can be mixed.
Do I need a battery with a grid-tie inverter?
No. A grid-tie micro inverter converts DC straight into 230V AC and feeds it into your home circuit. Batteries are only needed if you want off-grid storage — that requires a hybrid system instead.
How do I set up WiFi monitoring?
Scan the QR on the side of the unit in the free Solarman app, connect over WiFi, and you'll see live output, daily generation, error codes and system status from anywhere.
Can I limit the output power to meet my grid operator's rules?
Yes. Output is adjustable from 5% to 100% in the app — perfect for countries or utilities that cap how much you're allowed to feed back into the grid.
Do I need an electrician to install it?
The DC side (panels + MC4 connectors) is plug-and-play. The AC grid connection should always be wired and signed off by a certified installer.
What warranty do I get?
5 years of full parts-and-labor coverage, handled from our EU warehouse so there are no cross-border returns.
